| Lugar de origem: | Guang Dong, China. |
|---|---|
| Marca: | WEJOIN |
| Certificação: | CE;ISO |
| Número do modelo: | WJTS122 |
| Quantidade de ordem mínima: | 1SET |
| Preço: | USD+620-680+set |
| Detalhes da embalagem: | Caso de madeira |
| Termos de pagamento: | T/T. |
| Habilidade da fonte: | mês 3000+setsr+per |
| Material do alojamento: | 304 de aço inoxidável | comprimento do polo: | 490mm |
|---|---|---|---|
| Sentido de gerencio: | Sentido dobro | Tensão de funcionamento do motor: | DC12V |
| Realçar: | porta pedestre da barreira,portas da entrada da segurança,Torniquete datilografado vertical do tripé |
||
Functions & Features
Full-automatic type
(1). Stainless steel Housing.
(2). Bi-direction pass.
(3). Arms auto drop when power off.
(4). Arms auto rise up when power on and auto stop on obstacle.
(5). Traffic light indicator.
(6). Wingen 26/Dry contact, is compatible with smart card for access control.
(7). Photoelectric inspection.
(8). If the passenger does not pass in valid time, the passage will be locked up. And the valid passing time can be set up by operator.
(9). Passenger counters (optional).
| Model Item |
WJTS122 | ||
| Manual, Semi or Full-automatic | Full-automatic | ||
| Material of Housing | 304 Stainless Steel | ||
| Thickness of Housing | 1.50mm | ||
| Dimension of Housing (L×W×H mm) |
420×380×1000 | ||
| Length of Pole (out of housing) | 490mm | ||
| Net Weight | 50kg | ||
| Max Load-bearing of Pole | 80kg | ||
| Driving Force of Pole | 3kg | ||
| Rotating Direction | Double Direction | ||
| Power Supply | 220V±10%, 110V±10% | ||
| Frequency | 50/60HZ | ||
| Working Voltage of Motor | DC12V | ||
| Rated Power | 50W | ||
| Driving Motor | Brush DC Motor | ||
| Communication Interface | RS232 standard socket/LAN socket | ||
| Input Interface | DC12V electrical leveel signal, more than 10ms, or DC12V impulse signal driveing current, more 10mA | ||
| Transit Speed | 20~35 persons/min | ||
| Working Temperature | 15°C~55°C | ||
| Working Environment | Indoor / Outdoor (Shelter) | ||
| Relative Humidity | ≤90%, no condensation | ||
